ICS(P)A Cartesian Robot Assembly Procedures Manual
July 24th, 2009 Posted in New IAI Literature
ICS(P)A Cartesian Robot Assembly Procedures – 1st Edition
Manual #: ME0215-1A
Pages: 32
This manual contains assembly instructions on 14 different configurations for the ICS(P)A Cartesian Robot.
1. XYB (X-axis Base Mount)
2. XYB (Y-axis Base Mount)
3. XYG (Gantry) Type
4. XYS (Y-axis Slider Mount)
5. YZ (Y-axis Slider Mount)
6. XZ (Z-axis Base Mount)
7. X-Y Base Mount (XYB) + Z-axis, Z-axis Base Mount
8. X-Y Base Mount (XYB) + Z-axis, Z-axis Base Mount
9. X-Y Base Mount (XYB) + Z-axis, Z-axis Base Mount
10. X-Y Base Mount (XYB) + Z-axis, Z-axis Slider Mount
11. X-Y Gantry Configuration (XYG) + Z-axis, Z-axis Base Mount
12. X-Y Gantry Configuration (XYG) + Z-axis Slider Mount
13. XYB (Y-axis Base Mount)
14. XYB (Y-axis Mount)
Go to the Electric Actuator Manuals page to download this manual.
