Corrections Made on ICSA+NS System Cartesian Robot Assembly Manual

August 14th, 2009 Posted in Manual Updates

Minor corrections were made to page 4 of this manual. Some extra “2″s were removed from parts that were presented. Also, blurry images have been cleaned up.

p4correction

ME0196-1A

X-axis Nut Rotation Type Cartesian Robot Assembly Procedures – 1st Edition
Manual #: ME0196-1A
Pages: 17

This manual contains assembly instructions on six different configurations for the NS (nut rotation type actuator) + ISA configuration unit.

1. High-precision 2-axis specification
2. High-precision 3-axis specification, Z-axis base mount
3. High-precision 3-axis specification, Z-axis slider mount
4. High-precision 4-axis specification
5. High-precision 6-axis specification, Z-axis base mount
6. High-precision 6-axis specification, Z-axis slider mount

Go to the Electric Actuator Manuals page to download this manual.
